WORKSHOP MANUAL
Mount the screw unions on the travel motor, rmly tighten.
Material
Hydraulic motor K 04/340.0 cm³/rev. (1)
• (2x) Straight neck with thread GES10L M22x1.5 (2) (125 Nm)
• (1x) Straight neck with thread GES10L M16x1.5 (3) (55 Nm)
• (1x) Straight neck with thread GES10L M14x1.5 (4) (45 Nm)
Cover the screw unions with caps.
