182 ARR1575

557D425

557D426

557D404

557D427

7 Front drum

Mount the clutch.

If the old clutch is undamaged, you can reuse it. Otherwise, in-

sert anew clutch.

Apply sealant on the sealing surface.

Insert the vibration hydraulic motor.

Apply blue adhesive on the screws.
