229ARR1575

557D520

557D521

557D523

557D522

WORKSHOP MANUAL

Mount the 036 hydraulic hose on the screw union of the angled

divider.

Mount the 010 hydraulic hose on the screw union of the angled

divider.

Mount hydraulic hoses A1, B3, T3.

Connect the connectors in the back (Y5, Y8).
