Ammann ARR 1575 - Page 240

To Next Page

To Previous Page

238 ARR1575

557D239

557D240

557D241

11 Travel

Mount the safety pin on the plug head.

Connect cables Y2+ and Y2-.

Do not interchange the - and + cables.
