271ARR1575

557D634

557D635

557D636

557D637

WORKSHOP MANUAL

Place the stop on the right.

Insert the screw and apply blue adhesive on it.

Mount the washer and nut.

Tighten the screw rmly.

Tighten the screw rmly until the stop (1) lies in the tube with-

out agap.
