301ARR1575

557D024

557D025

557D026

557D027

WORKSHOP MANUAL

Remove the magnetic coil (1) from the magnetic valve (2).

Remove the hydraulic hose (030).

Pressure-close the screw connection.

Reinstall the magnetic coil.
