315ARR1575

557D066

557D067

557D068

557D069

WORKSHOP MANUAL

Mount the magnetic valve.

Install acleaned aperture with the holder and tighten rmly.

Check the plug seal.

Lubricate the seal slightly with oil.

Install both plugs and tighten rmly.
