FORMAT:
(All plugs):
• Image Size: Current image size (width x height) (/!\ signal aspect ratio and predefined crop settings
are taken into account). Width - in pixels; Height - in lines.
• Format Size: Useful signal format size (width x height). Width - in pixels; Height - in lines.
• Field Frequency: Frame frequency (in Hz).
• Line Frequency: Line frequency (in Hz).
• Sync Polarities: Positive H sync and V sync polarities.
• Scan Type: Interleaving type.
List of possible interleaving types:
INTERLACED TOP FIELD FIRST
Interlaced, Top field first
INTERLACED BOTTOM FIELD FIRST
Interlaced, Bottom field first
• Settings Memory Slot: Memory slot used for the input settings (0 means that no slot is used or that
default settings are used).
(HDMI/DVI plugs):
• HDMI mode: HDMI mode status (in DVI mode no audio can be transmitted).
(All except HD15):
• Repeat Coefficient: (DVI and HDMI signals only) Repetition coefficient for pixel.
• Color Space: Color space of the signal.
List of possible input color spaces (digital plugs):
Automatic color space selection
YUV (YCbCr ITU-R BT.601 or YCbCr BT.709)
RGB Limited scale (16-235)
• Color Depth: Color depth of the signal.
List of possible signal color depths:
18 bits for a pixel, 6 bits for each color
24 bits for a pixel, 8 bits for each color
30 bits for a pixel, 10 bits for each color
36 bits for a pixel, 12 bits for each color
• Lane: (DisplayPort plug only) Number of lanes.
List of possible DisplayPort lanes:
