To control the volume (master volume):
Front Panel
1. Enter the AUDIO menu on the Front Panel interface.
2. Select Output Settings to set up the audio output.
3. Select Master Volume to adjust the volume of the output audio.
Web RCS
1. Go to the Setup menu on the Web RCS interface.
2. Click on the AUDIO tab to access the audio management page.
3. In the left side toolbar, select General to access the audio inputs and outputs setup page.
NOTE: You can also access the audio outputs setup page via the A/V Mapping tab.
4. Under Main Audio (bottom left side window), click and drag the Volume control bar to adjust the
master volume.
TIP: Enable/disable the Master Mute button to mute/unmute the output audio (all channel pairs at once).
