USER MANUAL
Web RCS
1. Go to the Setup menu on the Web RCS interface.
2. Click on the OUTPUTS tab to access the outputs setup page.
3. In the left side toolbar, select Standard Output to access the standard output setup page.
4. Click on the Signal tab to access the output format setup page.
5. Under SIGNAL > Format Mode, select INTERNAL REF. to use the system clock as a reference to set
up the format.
6. Select a Format from the list of formats compatible with the internal reference mode.
Available output formats include:
SDTV PAL 4:3
SDTV PAL 16:9
SDTV NTSC 4:3
SDTV NTSC 16:9
CEA-861 480i 4:3
CEA-861 480i 16:9
EDTV 480p 4:3
EDTV 480p 16:9
EDTV 576p 4:3
EDTV 576p 16:9
HDTV 720p
HDTV 1035i
HDTV 1080i
HDTV 1080sF
HDTV 1080p
DCDM 2K (2048x1080)
UHDTV 2160p (3840x2160)
DCDM 4K (4096x2160)
DMT 640x480 (4:3 VGA)
800x480 (15:9 WVGA)
DMT 800x600 (4:3 SVGA)
DMT 848x480 (16:9 WVGA)
DMT 1024x768 (4:3 XGA)
1088x817 (4:3)
DMT 1152x864 (4:3)
DMT 1280x720 (16:9 720p)
DMT 1280x768 (15:9 WXGA)
DMT 1280x800 (16:9 WXGA2)
DMT 1280x960 (4:3)
DMT 1280x1024 (5:4 SXGA)
DMT 1360x768 (16:9)
DILA 1360x1024 (4:3)
DMT 1366x768 (16:9 WXGA)
1366x800 (15:9 WXGA)
DMT 1400x1050 (4:3 SXGAP)
DMT 1440x900 (16:10 900p)
DMT 1440x1080 (4:3)
DMT 1600x900 (16:9)
DMT 1600x1200 (4:3 UXGA)
DMT 1680x1050 (16:10 WSXGA+)
DMT 1792x1344 (4:3)
DMT 1856x1392 (4:3)
DMT 1920x1080 (16:9 FHD)
DMT 1920x1200 (16:10 WUXGA)
DMT 1920x1440 (4:3)
1920x2160 (UHD Side/Side)
2048x1080 (2K)
DMT 2048x1152 (16:9)
DILA 2048x1536 (4:3 QXGA)
2048x2160 (4K Side/Side)
CEA-861 2560x1080 (21:9)
CVT 2560x1440 (16:9 QHD)
DMT 2560x1600 (16:10 WQXGA)
CVT 2560x2048 (4:3 QSXGA)
CVT 3440x1440 (21:9)
3840x1080 (UHD Top/Bottom)
4096x1080 (4K Top/Bottom)
COMPUTER CUSTOM 1 ... 64
7. Select a Rate from a list of rates compatible with the chosen format.
8. Select APPLY to save and apply the new settings.
