To auto-set the format using EDIDs:
Front Panel
1. Enter the OUTPUTS menu on the Front Panel interface.
2. Select STANDARD OUTPUT to access the standard output setup menu.
3. Select Format to access the standard output format setup menu.
4. Select AUTO EDID FORMAT to auto-set the format using a plug's EDID preferred format.
5. Select the plug used for auto EDID and wait for the Format generation in progress screen.
6. Once the setup is complete, press the EXIT-MENU button to return to the output setup menu.
Web RCS
1. Go to the Setup menu on the Web RCS interface.
2. Click on the OUTPUTS tab to access the outputs setup page.
3. In the left side toolbar, select STANDARD OUTPUT to access the standard output setup page.
4. Click on the Signal tab to access the output format setup page.
5. Under SIGNAL > Format Mode, select AUTO EDID FORMAT. to auto-set the format using a plug's
EDID preferred format.
6. Click on Plug to select the plug used for auto EDID.
7. Select APPLY to save and apply the new settings.
