Table 7.4.3.1-1 Condition Tab Setting Commands
No. Item Command
[1] Tab Selection :DISPlay:RESult:EDIagram:TABSelect
:DISPlay:RESult:EDIagram:TABSelect?
[2] Slot Eye
Diagram
:SENSe:MEASure:EDIagram:DIAGram:SLOT
:SENSe:MEASure:EDIagram:DIAGram:SLOT?
[3] Slot Mask Test :SENSe:MEASure:EDIagram:MTESt:SLOT
:SENSe:MEASure:EDIagram:MTESt:SLOT?
[4] Transition Bit
Measurement
:SENSe:MEASure:EDIagram:DIAGram:TRANsition
:SENSe:MEASure:EDIagram:DIAGram:TRANsition?
[5] Measurement
Point
:SENSe:MEASure:EDIagram:DIAGram:TYPE
:SENSe:MEASure:EDIagram:DIAGram:TYPE?
[6] Auto Search :SENSe:MEASure:EDIagram:DIAGram:ASEarch
:SENSe:MEASure:EDIagram:DIAGram:ASEarch?
:DISPlay:RESult:EDIagram:TABSelect <tab>
Parameter <tab>=<CHARACTER PROGRAM DATA>
CONDition Condition tab
DIAGram Diagram tab
MASKedit Mask Edit tab
Function Switches the Eye Diagram measurement tab display.
Example To display the Eye Diagram measurement Condition tab:
> :DISPlay:RESult:EDIagram:TABSelect CONDition
Compatibility Incompatible with existing models.
:DISPlay:RESult:EDIagram:TABSelect?
Response <tab>=<CHARACTER RESPONSE DATA>
COND, DIAG, MASK
Function Queries the Eye Diagram measurement tab display.
Example > :DISPlay:RESult:EDIagram:TABSelect?
< COND
Compatibility Incompatible with existing models.
