7.4 Automatic Measurement Commands
7-67
7
Remote Commands
Table 7.4.3.2.2-1 Graph Display Setting Commands
No. Item Command
[1] Condition Detail Result :DISPlay:RESult:EDIagram:DIAGram:TABSelect
:DISPlay:RESult:EDIagram:DIAGram:TABSelect?
[2] Meas :SENSe:MEASure:EDIagram:DIAGram:THReshold
:SENSe:MEASure:EDIagram:DIAGram:THReshold?
[3] Meas set All
Meas reset All
:SENSe:MEASure:EDIagram:DIAGram:ATHReshold
[4] Display :DISPlay:RESult:EDIagram:ERATe
:DISPlay:RESult:EDIagram:ERATe?
[5] Display set All
Display reset All
:DISPlay:RESult:EDIagram:AERate
[6] Setting of error rate for
Estimate measurement
DISPlay:RESult:EDIagram:EERate
DISPlay:RESult:EDIagram:EERate?
[7] Mask :DISPlay:RESult:EDIagram:DISPlay:MASK
:DISPlay:RESult:EDIagram:DISPlay:MASK?
[8] Actual/Estimate :DISPlay:RESult:EDIagram:ESTimate
:DISPlay:RESult:EDIagram:ESTimate?
[9] Meas.ratio :SENSe:MEASure:EDIagram:DIAGram:BTHReshold
:SENSe:MEASure:EDIagram:DIAGram:BTHReshold?
[10] Query for measurement
point
:SENSe:MEASure:EDIagram:DIAGram:POINt?
[11] Query for measurement
result
:CALCulate:DATA:DIAGram?
:DISPlay:RESult:EDIagram:DIAGram:TABSelect <tab>
Parameter <tab>=<CHARACTER PROGRAM DATA>
CONDition Condition tab
RESult Result tab
Function Switches the tab display within the Diagram tab.
Example To display the Result tab within the Diagram tab:
> :DISPlay:RESult:EDIagram:DIAGram:TABSelect RESult
Compatibility Incompatible with existing models.
:DISPlay:RESult:EDIagram:DIAGram:TABSelect?
Response <tab>=<CHARACTER RESPONSE DATA>
COND, RES
Function Queries the tab selected in the Diagram tab.
Example > :DISPlay:RESult:EDIagram:TABSelect?
< COND
Compatibility Incompatible with existing models.
