Chapter 7 Remote Commands
7-68
:SENSe:MEASure:EDIagram:DIAGram:THReshold <thre>,<boolean>
Parameter <type>=<CHARACTER PROGRAM DATA>
E_3 to E_12 1E–3 to 1E–12/1 Step
<boolean>=<BOOLEAN PROGRAM DATA>
ON or 1 Selects ON
OFF or 0 Selects OFF
Function Sets the Eye Diagram measurement target error rate.
Example To set the Eye Diagram measurement target error rate to 1E–12:
> :SENSe:MEASure:EDIagram:DIAGram:THReshold E_12,ON
Compatibility Incompatible with existing models.
:SENSe:MEASure:EDIagram:DIAGram:THReshold?
Response <type>=<CHARACTER RESPONSE DATA>
E_3 to E_12 1E–3 to 1E–12
NONE When all OFF
The selected threshold options are returned, with separated by a comma(s).
Function Queries the Eye Diagram measurement target error rate.
Example > :SENSe:MEASure:EDIagram:DIAGram:THReshold?
< E_3,E_10,E_12
Compatibility Incompatible with existing models.
:SENSe:MEASure:EDIagram:DIAGram:ATHReshold <boolean>
Parameter <boolean>=<BOOLEAN PROGRAM DATA>
ON or 1 Sets all ON
OFF or 0 Sets all OFF
Function Sets all Eye Diagram measurement target error rates to be ON or OFF.
Example To set all Eye Diagram measurement target error rates to be ON:
> :SENSe:MEASure:EDIagram:DIAGram:ATHReshold ON
Compatibility Incompatible with existing models.
:DISPlay:RESult:EDIagram:ERATe <thre>,<boolean>
Parameter <type>=<CHARACTER PROGRAM DATA>
E_3 to E_17 1E–3 to 1E–17/1 Step
<boolean>=<BOOLEAN PROGRAM DATA>
ON or 1 Display select ON
OFF or 0 Display select OFF
Function Sets the target error rate of the Eye Diagram measurement result display.
Example To set the target error rate of the Eye Diagram measurement result display
to 1E–12:
> :DISPlay:RESult:EDIagram:ERATe E_12,1
