B.2 Setting RestrictionsSettings Common in Combination System
B-3
App
endix
A
ppendix B
B.2 Settings Common in Combination System
When the MU183040A/B or MU183041A/B is used in a Combination
system, some setting items will apply to all the other modules in the
Combination system.
Table B.2-1 shows whether the setting items are common or independent
in a Combination system.
Table B.2-1 Common/Independent Setting Items in Combination System
Setting
Function
Main Category Sub-Category Individual Setting Item
Common/
Independent
Result Switch of setting
items
Setting display format Independent
Result display format Independent
Time display format Independent
Error/Alarm
display
Error/Alarm measurement
result zoom display
Independent
Error/Alarm measurement
result sub window
open/close
Common
Start of Error/Alarm measurement Common
Stop of Error/Alarm measurement Common
Measurement Measurement
period (Gating)
Measurement period unit (Unit) Common
Measurement period time Common
Clock count for measurement period Common
Error count for measurement period Common
Block count for measurement period Common
Measurement processing method (Cycle) Common
Measurement result data display (Current) Common
Known data processing method (Calculation) Common
Known data display update cycle Common
Re-synchronization
(Auto Sync)
Re-synchronization execution Common
Threshold for automatic synchronization
function
Common
Synchronization method Common
Synchronization
method
(Sync Control)
Synchronization method Common
Unique pattern length for frame
synchronization
Common
PRGM pattern start position Common
Edit of synchronization mask pattern Common
