Appendix B Setting Restrictions
B-4
Table B.2-1 Common/Independent Setting Items in Combination System (Cont’d)
Setting
Function
Main Category Sub-Category Individual Setting Item
Common/
Independent
Measure-ment
(Continued)
Measurement
condition
(Error/Alarm
Condition)
Interval for EI and EFI measurements Common
Pattern* Mask Block Window execution Common
Block Window setting Common
Bit Window execution Common
Bit Window bit string setting Common
External Mask ON/OFF Common
Input Data input Input condition Independent
Differential type Independent
Data/XData selection Independent
Data input threshold Independent
XData input threshold Independent
Data input threshold differential type Independent
Data input threshold differential Independent
Data input termination setup dialog box
display
Independent
Data input termination condition Independent
Data input termination voltage Independent
Clock Input Selection Common
Standard for Recovered Clock Bitrate Common
Recovered Clock Bitrate Common
Loop Bandwidth Common
The value of division for calculating the Loop
Bandwidth
Common
Clock phase unit Independent
Clock phase variable (mUI) Independent
Clock phase variable (ps) Independent
Clock phase calibration Independent
Clock phase reference Independent
Clock phase variable (reference mUI) Independent
Clock phase variable (reference ps) Independent
Clock phase variable (Jitter Input) Common
*: Settings shared by the PPG are omitted here. For details, refer to
the
MU183020A 28G/32G bit/s MU183021A 28G/32G bit/s 4ch Pulse
Pattern Generator Operation Manual
.
