2.1 Preparation Before Use
2-7
2
Before Use
Figure 2.1.4-4 Connecting Control PC to Two MP186xAs
Figure 2.1.4-5 Connecting Control PC Using A USB Hub
Using other USB devices
Refer to the following for how to use commercially available USB devices
when MP1862A is in use.
Connect the USB device before starting the MP1800A; do not connect or
disconnect USB devices while using the MX180000A Control Software.
In addition, only read measurement data using a USB device after
exiting the MX180000A Control Software (closing selector screen).
Use a PC that meets or exceeds the following specifications.
MP186xA
MP186xA
Control PC with MX180000A
Control PC with MX180000A
USB connector
with
different
controller
USB
USB connector
with
the same
controller
USB connector
of the same
controller
MP186xA
Control PC with MX180000A
USB Hub
USB
