Chapter 1 Outline
1-8
Table 1.3.1-1 MX269018A Product Specifications (Cont’d)
Items Specifications
Received power measurement
MS2830A:
The function is enabled
when the MS2830A-088/188 Analog Signal Generator option is installed
or
when the MS2830A-020/120/021/121 Vector Signal Generator
option and MS2830A-029/129 Analog Function Extension option for
Vector Signal Generator is installed.
MS2840A:
The function is enabled
when the MS2840A-088/188 Analog Signal Generator option is installed
or
when the MS2840A-020/120/021/121 Vector Signal Generator
option and MS2840A-029/129 Analog Function Extension option for
Vector Signal Generator is installed.
RF signal output
Frequency setting range
Frequency setting resolution
Output setting level
MS2830A:
The performance complies with the MS2830A-088/188, or
MS2830A-020/120/021/121 and MS2830A-029/129.
MS2840A:
The performance complies with the MS2830A-088/188, or
MS2830A-020/120/021/121 and MS2840A-029/129.
100 kHz to 3000 MHz
1 Hz
–136 to –3 dBm (Frequency ≤ 25 MHz)
–136 to +15 dBm (Frequency > 25 MHz)
FM modulation
Frequency deviation setting
range
Frequency deviation setting
resolution
Frequency deviation accuracy
Internal AF signal source
Internal AF signal source
setting range
Internal AF signal source
setting resolution
DCS code setting range
0 to 100 kHz
0.1 Hz
±1% of a setting value (residual FM excluded)
Without MS2830A-018/118, or MS2840A:
AF Tone source × 2, Digital Code Squelch signal generator
With MS2830A-018/118 installed:
AF Tone source × 3, Digital Code Squelch signal generator
20 Hz to 40 kHz
0.1 Hz,
Setting value ±3 Hz on use of Digital Code Squelch signal
000 to 777 (Three-digit octal notation)
