3.5 Audio Generator Function
3-67
3
Measurement
Note:
The operation [1] and [2] are available when no parameter is
selected (See Figure 3.5.3-1). Press
to deselect the selected
parameter.
[3] Displaying PTT state
Displays whether PTT is On or Off. It is highlighted in orange when
PTT is On, and it is in grey when PTT is Off.
3.5.2 “Setting PTT””
[2]
[4]
[3]
[1]
Figure 3.5.3-2 Audio Generator Window (a parameter is selected)
[4] Parameter setting
Press
to select a parameter in the Audio Generator window
(See Figure 3.5.3-2).
The parameters can be selected by using
and .
The parameter values can be changed by using the rotary knob or
and .
3.5.1 “Setting Audio Generator”
Press
to deselect the selected parameter.
