Chapter 1 Outline
1-10
1.3.2 MS2830A-029/129/088/188/189 Product Specifications
Table 1.3.2-1 lists the specifications for the
MS2830A-029/129/088/188/189.
Table 1.3.2-1 MS2830A-029/129/088/188/189 Product Specifications
Items Specifications
Function and performance
The following specifications are added to the specifications of the
MS2830A-020/120/021/121 and MS2830A-022/122 installed.
Frequency
Range
MS2830A-088/188/189: 100 kHz to 3.6 GHz
MS2830A-029/129: Lower limit frequency: 100 kHz. The upper
limit frequency depends on the vector signal
generator installed.
Output level
Output level accuracy
When the MS2830A-029/129/088/188 is installed, in CW mode, at
18 to 28 °C:
Output level p [dBm]
–110 ≤ p ≤ –3 ±3.0 dB typ. (100 kHz ≤ frequency < 250 kHz)
Waveform generator
Available only when the MS2830A-189 is installed (when the
MS2830A-088/188 is installed)
1.3.3 MS2840A-029/129/088/188/189 Product Specifications
Table 1.3.3-1 lists the specifications for the MS2840A-029/129/088/188/189.
Table 1.3.3-1 MS2840A-029/129/088/188/189 Product Specifications
Items Specifications
Function and performance
The following specifications are added to the specifications of the
MS2840A-020/120/021/121 and MS2840A-022/122 installed.
Frequency
Range
MS2840A-088/188/189: 100 kHz to 3.6 GHz
MS2840A-029/129: Lower limit frequency: 100 kHz. The upper
limit frequency depends on the vector signal
generator installed.
Output level
Output level accuracy
When the MS2840A-029/129/088/188 is installed, in CW mode, at
18 to 28 °C:
Output level p [dBm]
–110 ≤ p ≤ –3 ±3.0 dB typ. (100 kHz ≤ frequency < 250 kHz)
Waveform generator
Available only when the MS2840A-189 is installed (when the
MS2840A-088/188 is installed)
