Chapter 3 Measurement
3-90
Stop Frequency
■
Summary
Sets the Stop Frequency for distortion factor measurement.
■
Setting range
Manual Frequency set value for distortion factor measurement to
60000 Hz
Unit
■
Summary
Sets the unit of distortion factor measurement.
■
Options
dB Displays the distortion factor measurement
results in dB.
% Displays the distortion factor measurement
results in %.
3.9.4 Setting Meter
This section describes the meter settings for SINAD, THD, THD+N, and
AF Level. Press
(Meter Settings) in Page 2 of the Audio Analysis
function menu to display the Meter Settings function menu. Select
SINAD, THD, THD+N, or AF Level and perform the meter settings.
Reference Minimum
■
Summary
Sets the reference of the meter.
Enabled when Meter is set to On.
■
Options
Minimum Displays the meter with the minimum value as
reference.
Center Displays the meter with the center value as
reference.
Maximum Displays the meter with the maximum value as
reference.
Reference Value
■
Summary
Sets the reference value of the meter display.
Enabled when Meter is set to On.
■
Setting range
When the Unit is dB: –100.0 to 100.0 dB
When the Unit is AFLU: 0.000 to 1000.000
When the Unit is %: 0.00 to 10000.00%
