Chapter 3 Measurement
3-58
3.5 Audio Generator Function
When the MS2830A-018/118 Audio Analyzer is installed, the MS2830A
can output AF signals in TX measurement mode (Audio Generator
function).
3.5.1 Setting Audio Generator
Press (Audio Generator Setting) in the main function menu to
display the Audio Generator Setting function menu.
Waveform
■
Summary
Sets AF signal mode to output.
■
Options
Tones Outputs Tone signal.
Tone+DCS Outputs Tone signal + DCS signal.
Noise Outputs Tone signal or Noise signal (pseudo
voice).
DTMF Outputs DTMF (Dual Tone Multiple Frequency)
signal.
All Off Does not output AF signal.
Output Tone1
■
Summary
Sets Tone1 to On/Off.
■
Options
On Sets Tone1 to On.
Off Sets Tone1 to Off.
Tone1 Freq
■
Summary
Sets the Tone1 frequency.
■
Setting range
10.0 to 50000.0 Hz
Tone1 Level
■
Summary
Sets the Tone1 level.
