Chapter 2 Preparation
2-16.
2.4 Initialization and Calibration
This section describes the parameter settings and the preparations
required before starting measurement.
2.4.1 Initialization
After selecting this application, first perform initialization. Initialization
should be performed in order to return the settable parameters to their
default settings.
The initialization procedure is as follows.
■ Procedure
1. Press
to display the Preset function menu.
2. Press
(Preset).
2.4.2 Calibration
Perform calibration before measurement. Calibration sets the level
accuracy frequency characteristics for the input level to flat, and adjusts
level accuracy deviation caused by internal temperature fluctuations.
Calibration should be performed when first performing measurement
after turning on power, or if beginning measurement when there is a
difference in ambient temperature from the last time calibration was
performed.
■ Procedure
1. Press
to display the Application Cal function menu.
2. Press
(SIGANA All).
For details on calibration functionality only executable with the MS2830A
or MS2840A, refer to
MS2830A Signal Analyzer Operation Manual
(Mainframe Operation) or MS2840A Signal Analyzer Operation Manual
(Mainframe Operation)
.
