Chapter 1 Outline
1-6
1.3.1 MX269018A Product Specifications
Table 1.3.1-1 shows the specifications of MX269018A.
Transmitter power measurement specification is specified, when
MS2840A or MS2830A-062/066 Low Phase Noise Performance option is
installed.
Table 1.3.1-1 MX269018A Product Specifications
Items Specifications
Transmitter power measurement
Target signal
Setting frequency range
Measured level range
Carrier frequency accuracy
FM,
φ
M, AM modulation signal
FM,
φ
M, AM measurement:
100 kHz to the upper limit of the main unit
Wide Band FM measurement:
10 MHz to the upper limit of the main unit
–15 to +30 dBm (at Pre-Amp Off, or Pre-Amp not installed.)
–25 to +10 dBm (at Pre-Amp On)
After CAL execution at 18 to 28
°
C:
±(Reference frequency accuracy
×
carrier frequency + 1) Hz
FM measurement
Frequency deviation (FM)
Frequency deviation
(Wide Band FM)
Demodulation frequency range
Frequency deviation accuracy
Residual FM
Modulation distortion
DCS measurement function
FM measurement performance is defined in the following
conditions.
100 kHz
≤
frequency
≤
2700 MHz (FM measurement)
10 MHz
≤
frequency
≤
2700 MHz (Wide Band FM measurement)
0 < Frequency deviation ≤ 20 kHz
20 kHz < Frequency deviation ≤ 40 kHz (Nominal)
0 < Frequency deviation ≤ 20 kHz
20 kHz < Frequency deviation ≤ 1 MHz (Nominal)
20 Hz to 20 kHz
1% of an indication value ± residual FM
3.35 Hz rms, SN > 50 dB
(at 1.5 kHz deviation, demodulation bandwidth: 0.3 to 3 kHz)
0.3% (at demodulation frequency: 1 kHz, frequency deviation: 5
kHz, demodulation bandwidth: 0.3 to 3 kHz)
Code demodulation result display for Digital Code Squelch
