Chapter 3 Measurement
3-24
3.4 TX Measurement Mode
This measurement mode is for the radio transmission test. Parameters
can be set for measurement of signals input to the RF Input connector of
this instrument.
RX measurement mode parameters of RX Frequency and Output Level
can be set even in the TX measurement mode.
3.4.1 Setting frequency
This section describes the frequency-related settings. Pressing
(Frequency) in the main function menu displays the Frequency function
menu. Pressing
displays the Frequency function menu.
TX Frequency
■
Summary
Sets a frequency for transmission measurement.
This is available when Coupled Frequency is set to Off.
■
Setting range
100 kHz to the upper limit depending on main unit
Auto Detect
■
Summary
Detects signal frequency input to RF Input in the range of 300 kHz
to 2.7 GHz, and sets an analyzable value to TX Frequency
automatically.
Auto Detect Range Setting
■
Summary
Sets the frequency range to search by Auto Detect. When the DUT
frequency range is known in advance, the search duration can be
shortened by limiting the range.
Up to 8 frequency ranges can be specified.
Auto Detect Range Setting - Edit Number
■
Summary
Specifies a frequency range number to search by Auto Detect.
■
Setting range
1 to 8
To Next Page
