3.7 RX Measurement Mode
This measurement mode is for the radio reception test. Under the
following conditions, this measurement mode is available.
● The Analog Signal Generator (MS2830A-088/188, MS2840A-088/188)
or the Analog Function Extension Option for Vector Signal Generator
(MS2830A-029/129, MS2840A-029/129) is installed.
Parameters for signals output from the SG Output connector of this
instrument can be set.
3.7.1 Setting frequency
Configures settings related to frequency. Press (Frequency) in the
main function menu to display the Frequency function menu. Pressing
displays the Frequency function menu.
RX Frequency
■
Summary
Sets a frequency for output signal.
This is available when Coupled Frequency is set to Off.
■
Setting range
100 kHz to 3 GHz
TX/RX Frequency
■
Summary
Sets frequencies for TX and RX at the same time.
This is available when Coupled Frequency is set to On.
■
Setting range
Refer to the setting range of RX Frequency.
Coupled Frequency
■
Summary
Sets the function to couple the TX Frequency setting with the RX
Frequency setting.
■
Options
On Changes the RX Frequency setting value to the
TX Frequency setting value, and enables the
TX/RX Frequency setting items that are common
settings for TX and RX.
Off Disables the coupling of the TX Frequency to the
RX Frequency.
