4.4 Example of Performance Test Result Form
RF Performance Test
Table 4.4-1 Residual FM
Frequency Measured Value [Hz] Specifications Pass/Fail
100 kHz
3.35 Hz
400 MHz
2700 MHz
Table 4.4-2 Residual

M
Frequency Measured Value [rad] Specifications Pass/Fail
100 kHz
0.01 rad
400 MHz
2700 MHz
Table 4.4-3 Residual AM
Frequency Measured Value [%] Specifications Pass/Fail
100 kHz
0.30%
400 MHz
2700 MHz
Output Level Calibration:
Table 4.4-4 Value of Syscal
Calibration Level
(mV rms)
Syscal_Unbal
(mV rms)
Syscal_Bal
(mV rms)
3500
1400
700.0
350.0
35.00
7.000
