Chapter 3 Measurement
3-46
3.4.8 Setting AF Measure Result (TX-AF) graph
This section describes the graph settings in the AF Measurement Result
(TX-AF) window.
Pressing
(Graph Setting) on the main function menu, (Trace) on
Page 2 of the Modulation Analysis function menu, or
displays the
Trace function menu.
Graph Select
■
Summary
Sets the graph type in the AF Measurement Result (TX-AF)
window.
■
Options
Time Domain Sets the Time Domain graph to On/Off.
Frequency Domain
Sets the Frequency Domain graph to On/Off.
3.4.8.1 Setting Time Domain graph
This section describes the setting for the Time Domain graph. Press
(Time Domain Setting) on the Trace Function menu to display the Time
Domain Setting Function menu. The setting is enabled when Time
Domain is set to On.
Time Range
■
Summary
Sets the horizontal scale (X-axis) in the Time Domain graph.
■
Setting range
1 to 200 ms
The following vertical scale (Y-axis) can be set only when TX Modulation
is set to FM.
Scale Mode
■
Summary
Sets Auto scale/Fixed scale of the vertical scale (Y-axis) in the Time
Domain graph.
■
Options
Auto Sets the vertical scale to Auto scale.
Fixed Sets the vertical scale to Fixed scale.
