Anritsu MX269018A - Audio Analyzer Basic Settings; Audio Analyzer Function

Chapter 3 Measurement
3-84
3.9 Audio Analyzer Function
When the MS2830A-018/118 Audio Analyzer is installed, AF signals can
be input from the DUT to the MS2830A and analyzed in RX measurement
mode (Audio Analyzer function).
3.9.1 Audio Analyzer basic settings
Press (Measure) and then press (Audio Analysis) in the main
function menu to display the Audio Analysis function menu.
This section explains the basic settings of the Audio Generator.
Input Type
■
Summary
Selects balanced/unbalanced input of AF signal.
■
Options
Bal. Balanced input.
Unbal Unbalanced input.
Input Range
■
Summary
Sets the range for AF input signal.
■
Options
50mVp Sets the AF input signal range to 50 mV.
500mVp Sets the AF input signal range to 500 mV.
5Vp Sets the AF input signal range to 5 V.
50Vp Sets the AF input signal range to 50 V.
Input Impedance Reference
■
Summary
Sets the impedance reference used for converting AF Level
measurement value into power of W, dBm.
■
Setting range
0.01 to 1000 000 000.00

