Chapter 3 Measurement
3-68
3.6 Simultaneous Use With Other Applications
When the MS2830A-018/118 Audio Analyzer is installed, the Audio
Generator function and other applications (Spectrum Analyzer, Signal
Analyzer, etc.) can be used simultaneously.
Input audio signal in the DUT and measure occupation bandwidth or
spurious using Spectrum Analyzer.
Press
(Measure) in the main function menu and press (Switch
Application with Audio Generator). The screen of the previously-used
application appears and the Audio Generator window will be downsized.
Generator Window Position
■
Summary
Sets the display position of the downsized Audio Generator screen.
■
Options
Bottom Displays the Audio Generator screen under the
other application screen.
Top Displays the Audio Generator screen above the
other application screen.
Back to AMA
■
Summary
Quits the joint screen with the other application and displays the
screen of this application only.
