Anritsu VNA Master MS2024B User Manual

Signal Standards
MS20xxB UG PN: 10580-00301 Rev. D B-3
NMT-450-25 kHz - Downlink 459 18 1-300
NMT-470-20 kHz - Uplink 486.5 15 1972-2016
NMT-470-20 kHz - Downlink 486.5 15 1972-2016
NMT-900 - Uplink 925 70 1-1000
NMT-900 - Downlink 925 70 1-1000
NMT-900 (Offset) - Uplink 925 70 1025-2023
NMT-900 (Offset) - Downlink 925 70 1025-2023
NTACS - Uplink 878.5 93 1-1199
NTACS - Downlink 878.5 93 1-1199
PDC 800 Analog - Uplink 891.5 97 0-1680
PDC 800 Analog - Downlink 891.5 97 0-1680
PDC 1500 (JDC) - Uplink 1513 72 0-960
PDC 1500 (JDC) - Downlink 1513 72 0-960
PHS - Uplink 1906.5 23 1-77
PHS - Downlink 1906.5 23 1-77
SMR 800 - 12.5 kHz - Uplink 836 60 1-1199
SMR 800 - 12.5 kHz - Downlink 836 60 1-1199
SMR 800 - 25 kHz - Uplink 836 60 1-600
SMR 800 - 25 kHz - Downlink 836 60 1-600
SMR 1500 - Uplink 1483 60 1-479
SMR 1500 - Downlink 1483 60 1-479
TACS - Uplink 925 70 1-1000
TACS - Downlink 925 70 1-1000
UMTS/WCDMA - Uplink 1920 70 9600-9900
UMTS/WCDMA - Downlink 2110 70 10550-10850
UMTS/Region 2 - Uplink 1850 70 9250-9550
UMTS/Region 2 - Downlink 1930 70 9650-9950
802.11a 5170 84 34-161 (not all valid)
802.11b 2442 84 1-14
802.11 DS 2448 72 1-14
802.11 FH 2448.5 93 2-95
802.11g 2442 84 1-14
Table B-1. Signal Standards
Signal Standard
Center
(MHz)
Span
(MHz)
Valid Channels
