Anritsu VNA Master MS2024B - Delete Files; Delete Dialog Box

4-3 Managing Files File Management
4-6 PN: 10580-00301 Rev. D MS20xxB UG
Delete Files
Press the Delete soft key (submenu key). Highlight the file to be deleted with the touchscreen
or the Up/Down arrow keys. Press the Select or De-Select key. Selected files are outlined in
blue. Press the Delete key and then press Enter to delete the selected file.
Delete Dialog Box
Press the Delete soft key to open the Delete dialog box (Figure 4-4). The menus allow sorting
by file type, name, and saved date. Refer to the “Delete Menu” on page 4-14 for additional
information.
Figure 4-4. Delete Dialog Box
