4-3 Managing Files File Management
4-2 PN: 10580-00301 Rev. D MS20xxB UG
4-3 Managing Files
Press the Shift key then the File (7) key on the numeric keypad to list the File menu. Follow
the additional steps below.
Save Files
Set the Save Location
Press Save then the Change Save Location soft keys (submenu keys) and select the location to
save files. You can save files to the internal memory or to an external USB flash drive. You
can also create new folders. If an external USB flash drive is connected or disconnected, press
Refresh Directories to update the location tree. Press the Set Location key to store the save
location.
Save Measurement As
The Save Measurement As key is used to quickly save measurements with a specific file
name. The VNA Master saves the measurement with the latest file name that was used to
save a measurement and with a number that is automatically incremented and appended to
the end of the file name. For instance, if the last measurement was saved with the name
System Return Loss, Save Measurement As saves the next measurement as System Return
Loss_#1, System Return Loss_#2 etc. The file name used can be changed using the Save
dialog box (Figure 4-1).
Save a Measurement
Press the Save Measurement key and enter the name for the measurement file. The
measurement file can be stored as .MNA.
Save a Setup
Press the Save soft key, type a name for the setup file, confirm that the file type is Setup
using the Change Type key or the touchscreen, and then press Enter to save.
Create a Menu Shortcut for a Setup File
Press the Recall soft key to display saved setup files. Locate the setup file to shortcut and
then press and hold on the file name for a few seconds. Select a location in the shortcut grid to
save the setup file.
Save a Measurement Screen as JPEG
Press the Save soft key, type a name for the JPEG file, confirm that the file type is Jpeg, and
press Enter to save.
Note
When navigating through the File menu, pressing the Esc key returns to the
previous menu.
