MS20xxB UG PN: 10580-00301 Rev. D 3-1
Chapter 3 — Quick Start Guide
3-1 Introduction
This chapter provides a brief overview of basic measurement setups. For detailed
measurement information, refer to a specific measurement guide listed in
Appendix A, “Supplemental Documentation”. This chapter provides quick start measurement
information for the following measurement modes:
• Section 3-3 “Vector Network Analyzer” on page 3-2
• Section 3-5 “Spectrum Analyzer” on page 3-9
3-2 Measurement Mode Selection
Press the Menu key and use the touch screen to select the appropriate measurement icon.
Figure 3-1. Menu Screen with Icons for Installed Measurement Modes
Note The display of the Menu screen varies depending on installed options.
