4-5 File Menu File Management
4-10 PN: 10580-00301 Rev. D MS20xxB UG
Save Location Menu
This menu and dialog box are used to create folders and to select the location where the
VNA Master saves the current file. Select folders or drives with the Up/Down keys, the rotary
knob, or the touch screen.
Key Sequence: File > Save > Change Save Location
Note
Only folders (not files) are visible in the Save Location dialog box. To view files, use
the “Recall Menu” on page 4-12.
Sort By
Name Date type: Press this soft key (submenu key) to sort the folders by
Name, Type, or Date.
Sort Order
Asc Desc: Press this soft key to display the folder names in ascending or
descending order.
Create Folder: Press this soft key to create a new folder in the highlighted
location or folder. Name the new folder in the create directory dialog box.
Set Location: Press this soft key to set the current location for saving files
and then return to the “Save Menu” on page 4-9.
Refresh Directories: Press this soft key to update the display.
Figure 4-8. Save Location Menu
Figure 4-9. Select Save Location Dialog Box
Sort By
Name Date Type
Sort Order
Asc Desc
Create
Folder
Set
Location
Refresh
Directories
Save Location
