System Operations 5-3 System Menu
MS20xxB UG PN: 10580-00301 Rev. D 5-3
5-3 System Menu
Key Sequence: Shift, System (8)
Status: Press this submenu key to display the current system status,
including the operating system and firmware versions, temperatures, and
other details such as current battery information. Press Esc or Enter to return
to normal operation.
Self Test: Press this submenu key to run a series of tests that are related to
the performance of the motherboard hardware. Press the Esc key to abort, or
press the Enter key to continue. The display lists a summary of those tests
that have passed. If any test fails, then all of the performed tests are listed
with Pass/Fail notification.
If the Self Test fails when the battery is fully charged and the instrument is
within the specified operating temperature, then contact your Anritsu Service
Center and report the test results. Press Esc or Enter to return to normal
operation.
Application Self Test: Press this submenu key to run a series of tests that
are related to the performance of the instrument hardware and that are
specific to the current instrument application. Press the Esc key to abort, or
press the Enter key to continue. The display lists a summary of those tests
that have passed. If any test fails, then all of the performed tests are listed
with Pass/Fail notification. If any test fails, then contact your Anritsu Service
Center and report the test results.
GPS: Press this submenu key to open the GSP Menu. Refer to
Chapter 6, “GPS (Option 31) ” for additional information.
Application Options: Submenu keys are specific to each measurement
mode: “Application Options Menu (VNA Mode)” on page 5-6
“Application Options Menu (SPA Mode)” on page 5-7.
System Options: Press this submenu key to open the “System Options
Menu” on page 5-4.
Figure 5-2. System Menu
System
System
Options
Application
Options
GPS
Status
Self
Test
Application
Self
Test
Calibrate
Touch
Screen
To Next Page
