1-10 Tilt Bail Stand
A Tilt Bail is attached to the back of the VNA Master for desktop operation. The tilt bail
provides two settings of backward tilt for improved stability. To deploy the tilt bail, pull the
bottom of the tilt bail away from the back of the instrument. To store the tilt bail, push the
bottom of the bail towards the back of the instrument until it attaches to the VNA Master.
Note
Do not use the tilt bail while the instrument is in the soft case. The soft case has an
adjustable support panel in the back zipper.
Figure 1-4. Tilt Bail Extended
