4-5 File Menu File Management
4-8 PN: 10580-00301 Rev. D MS20xxB UG
4-5 File Menu
Key Sequence: File
Save Measurement As: Press this soft key (submenu key) to save the
current setup with a user defined filename. The default filename is changed
using the Save menu. To change the default file name, type in a new file with
the touch screen keyboard and press Enter. After a few seconds, the screen
returns to File menu. Press the Save Measurement As key again and the
new file name is used.
Save Measurement: Press this soft key to display the “Save Menu”
on page 4-9 and the touch screen keyboard. Measurements can be saved to
internal memory or to a USB flash drive. The saved measurement can be
named by using the touch screen keyboard. By default, measurements are
saved to internal memory in a directory named /user. The save destination is
set with the “Save Location Menu” on page 4-10.
Save: Press this soft key to display the “Save Menu” on page 4-9 and the
touch screen keyboard. Measurements can be saved to internal memory or
to a USB flash drive. The saved setup, measurement, or JPEG file can be
named by using the touch screen keyboard. By default, measurements are
saved to internal memory in a directory named /user. The save destination is
set with the “Save Location Menu” on page 4-10.
Save on Event: Press this soft key to display the “SaveOnEvent Menu”
on page 4-11. This soft key is displayed only in Spectrum Analyzer and
Interference Analyzer modes.
Recall Measurement: Press this soft key to display the “Recall Menu”
on page 4-12. This menu is for recalling measurements from internal
memory or from a USB flash drive.
Recall: Press this soft key to display the “Recall Menu” on page 4-12. This
menu is for recalling measurement or setup data from internal memory or
from a USB flash drive.
Copy: Press this soft key to display the “Copy Menu” on page 4-13. The
Copy menu is for copying files or folders from internal memory or a USB
flash drive.
Delete: Press this soft key to display the “Delete Menu” on page 4-14 and a
selection box that shows the setup and measurement names and the type,
date, and time that the information was saved. Use the rotary knob or the
Up/Down arrow keys to highlight the file that is to be deleted and press the
Delete soft key, then press Enter. Press the Esc key to cancel the operation.
Note that deleted files cannot be recovered.
Figure 4-6. File Menu
File
Copy
Recall
Recall
Measurement
Recall
Save
On
Event
Save
Save Measurement As
FileName.vna
Save
Measurement
Delete
