Instrument Overview 2-3 Front Panel Overview
MS20xxB UG PN: 10580-00301 Rev. D 2-3
2-3 Front Panel Overview
The VNA Master menu-driven interface is easy to use and requires little training. The
VNA Master uses a touch screen and keypad for data input. The five bottom menu keys and
eight soft keys (submenu keys) on the right side are touch screen keys. The menu and soft
keys vary depending upon the selected mode of operation. Refer to “Mode Selector Menu”
on page 2-21.
Numeric keys 1 through 9 are dual purpose, depending upon the current mode of operation.
The dual-purpose keys are labeled with a number on the key itself, and the alternate function
is printed in blue above each of the keys. Use the blue Shift key to access the functions that
are printed on the panel. The Escape key, used for aborting data entry, is the oval button
located above numeric key 9. The rotary knob, the four arrow keys, and the keypad can be
used to change the value of an active parameter.
The Menu key provides graphical icons of all of the installed measurement modes and user
defined shortcuts (refer to “Menu Key” on page 2-4). The locations of the keys are shown in
Figure 2-1.
Caution
Keep the fan inlet and exhaust ports clear of obstructions at all times for proper
ventilation and cooling of the instrument.
