Position the toothed oil pump control
wheel paying attention to the internal
sliding rollers.
•
Place the shim washer before positioning a new oil pump control gear fixing Seeger ring.
•
Close the crankcase.
•
Fit the clutch.
THE COUPLE OF GEARS HAS THE SAME SHAPE AS THAT
FOR THE STREET MODEL BUT IT IS NOT INTERCHANGE-
ABLE.
IN ORDER TO IDENTIFY THE CORRECT COUPLE OF
GEARS THAT BELONG TO THIS VEHICLE, CHECK THAT
THERE IS THE CORRESPONDING CUT ALONG THE
TOOTH WHEEL.
Kickstart
Start-up pedal removal
•
Remove the clutch.
•
Loosen the spring grub screw.
Engine MXV 450
ENG - 150
