Working from both sides, undo and re-
move the radiator upper screw.
•
Lift both radiators by sliding them off
the aluminium tubes on the crankcase.
•
Plug and tie the aluminium tubes using
an elastic band to keep them in their
correct position.
•
Working from both sides, release the
inlet duct.
•
Working from the left side, unscrew
and remove the swingarm pin nut.
•
Partially slide off the swingarm pin and insert a plug with a diameter suitable to fit the hole
on the left side.
•
Do not remove the swingarm pin completely.
•
Undo and remove the engine lower fix-
ing screw.
MXV 450 Engine from vehicle
ENG VE - 75
