Working from the right side, unscrew
and remove the upper nut.
•
From the opposite side, slide off the
screw.
•
Collect the spacers.
•
Lower the engine.
•
After removing the engine, operate on the engine block and place it on the corresponding
engine support plate.
Specific tooling
9100841 Engine support
Installing the engine to the vehicle
•
Place the engine block.
•
Move the engine with small alternating
movements until it is perfectly aligned
with the fixing holes.
•
Fit the swingarm pin.
•
Insert the upper screw, fit the washers
and tighten the nut.
Engine from vehicle MXV 450
ENG VE - 76
