Arjo Tornado - Page 27

27
Line, Sub-line Parameter Setting,
basic
Setting,
range
Authorization
63 nn Counter for error code Fnn 0-99 errors C
Lines 70-74: Program statistics
70 - Max. temperature 5-99°C -
71 - Program time, last process 0-9999 seconds -
72 - Program time, total 0-99999 seconds -
73 - Counter for number of
processes
0-99999 -
74 01 Counter, program 1 0-9999 C
74 nn Counter, program nn 0-9999 C
Line 80-83: Function test
80 - Display test 1 = activate LEDs
and display
C
81 01 Reading input 1 (max 14) 0 = off, 1 = on -
81 nn Reading input nn 0 = off, 1 = on -
82 01 Control, output 1 (max. 26) 0 = off, 1 = on C
82 nn Modulation output. nn 0 = off, 1 = on C
83 01 Reading temperature C/F 0-150°C
32-302°F
-
83 02 Reading temperature C/F
independent
0-150°C
32-302°F
-
Lines 85-86: Flash
85 - 6DYHFRQ¿JLQÀDVK
86 - /RDGFRQ¿JIURPÀDVK
Lines 87-88: AD calibration
87 - Calibrate AD
88 - Calibrate independent AD
Line 96: Activation, inputs
96 01 Activation, level A 1 Input: 0 = not
active, 1 = active
C
96 02 Activation, level B 1 Input: 0 = not
active, 1 = active
C
96 03 Activation, level C 1 Input: 0 = not
active, 1 = active
C
96 04 Activation descaler, low
level
1 Input: 0 = not
active, 1 = active
C
96 05 Activation descaler empty 0 Input: 0 = not
active, 1 = active
C
96 06 Activation chemical agent
low level
0 Input: 0 = not
active, 1 = active
C
96 07 Activation chemical agent
empty
0 Input: 0 = not
active, 1 = active
C
