ASL INTERCOM VAR8 User Manual

VAR8 and Variants Operation, Commissioning, Fault Finding, and Maintenance Guide -
Is
Page 146 of 166
sue: 02 complete, approved
VAR8 Menu Description
Ref. Item Description/Possible Settings
Select DVA
Applicable when a button is configured for Play DVA. Allows the selected button
to have a DVA input associated with it. The outputs in question are the outputs
which have been pre-selected using buttons configured for zone selection. The
input DVA may be either an Audio Control Unit DVA (NETWORK IP), or one of
the Slave Unit DVAs (LOCAL IP).
Default value:
‘Not-Conf’
156 Control
Applicable when the selected contact is configured for DVA Routing or Play DVA.
Having selected this option the sub-menus ‘Latching’, ‘Busy=on’, and ‘DVA-Full’
are displayed for routing control configuration.
157 Clear-all
Enables the user to clear the route associated with the DVA Routing or Play DVA
button.
158 Input
Defines a gain to be applied to the input audio, in respect of any output to which
it may be routed.
Possible values:
–63dB to 0dB (1dB steps)
Default values:
Mic/Line Input: –20dB
Miscellaneous Input: –20dB
Network Channel: –20dB
Music Input: –25dB
L The default setting for an ASL microphone is –14dB. With ASL
microphones any further volume adjustments should be made using the
output specific relative gains, see step 159.
L Input gain is not available for Mute input.
L Network Channel input gain should be set to its default value
(–20dB).
159 Output
Defines a gain to be applied to the input audio, separately for each output to
which it may be routed.
Possible values:
–40dB to 0dB (1dB steps)
Default value:
‘0dB’
L Output gain is not available for Mute input.
L Network Channel output gains should be set to its default value (0dB).
160 Latching
Defines whether the button in question (DVA Routing or Play DVA) is used to
both make and clear the route.
• ‘Not Latched’
The first press of the button in question (DVA Routing or Play DVA) initiates
the route, and the second press terminates it.
• ‘Latched’
A reset button is also defined; in this configuration the play DVA or DVA
routing button initiates the route, and the reset button terminates it.
If ‘Latched’ has been chosen, the user can identify the button that will act as
the reset button.
• ‘Play Once’
If this mode is selected then pressing a DVA Routing plays the DVA
associated with the route once only.
Default value:
‘Not Latched’
161 Busy=On
Defines whether or not this route should cause busy indication on the LEDs
associated with microphone zone select buttons.
Possible values:
‘On’ or ‘Off’
Default value:
‘On’
162 DVA-Full
Defines whether, when the route is terminated, the DVA shall cease playing
immediately or play until its end.
Possible values:
‘DVA-Full’ or ‘DVA-Part’
Default value:
‘DVA-Full’
163 Faults
(V1.5.0115 or later)
Access to Frame learn check function.
