Automationdirect.com Stride SIOL-EI8B - Page 8

SIOL-EI8B-USER-M
iii
Powered by
Version 1, May 2022
Table of Contents
iii
9.3.1. Reading an IO-Link device index 64
9.3.2. Writing an IO-Link device index 65
9.3.3. CIP status codes 66
10. Web Server (WebUI) 67
10.1. Starting the WebUI 68
10.2. Menu bar 69
10.2.1. STATUS menu 69
10.2.2. PARAMETERS menu 71
10.2.3. DIAGNOSTICS menu 71
10.2.4. MAINTENANCE menu 72
10.3. IO-Link Master Port 73
10.3.1. STATUS menu 73
10.3.2. INFORMATION menu 75
10.3.3. CONFIGURATION menu 76
10.3.4. IO-LINK PARAMETER menu 76
10.3.5. PROCESS DATA menu 77
10.4. Settings / Maintenance 78
10.4.1. DEVICE CONFIGURATION menu 78
10.4.2. MAINTENANCE INFORMATION menu 79
10.4.3. FIRMWARE menu 80
10.4.4. FACTORY RESET menu 80
10.5. User Administration 81
10.6. Digital IO Channels / IO Overview 81
10.6.1. Input data 81
10.6.2. Output data 82
11. Maintenance and cleaning 84
Appendix A: Supported EtherNet/IP objects 85
A.1. Standard object class 85
A.1.1. Identity Object (Class Code: 0x01) 85
A.1.2. Message Router Object (Class Code: 0x02) 86
A.1.3. Assembly Object (Class Code: 0x04) 86
A.1.4. Connection Manager Object (Class Code: 0x06) 87
A.1.5. Device Level Ring (DLR) Object (Class Code: 0x47) 87
A.1.6. Quality of Service Object (Class Code: 0x48) 88
A.1.7. TCP/IP Interface Object (Class Code: 0xF5) 89
A.1.8. Ethernet Link Object (Class Code: 0xF6) 90
A.2. Vendor Specic Objects 92
A.2.1. IO-Link Device Parameter Object (Class Code 0x83) 92
Appendix B: Explanation of the process data 94
B.1. System Status 94
B.2. IO-Link Port X Status 95
