Chapter 10: Universal Digital Trunk card
maintenance
Contents
This section contains information on the following topics:
Enable UDT card on page 91
Maintenance and diagnostics on page 93
Enable UDT card
Enable the UDT
card in Call Server, as described in the following sections.
Enable UDT card configured as PRI/PRI2
1.
In LD 60 enable the 2.0 Mb PRI loop:
ENLL L
2. In LD 96 enable the MSDL (implemented on board):
ENL MSDL l s c
3. In LD 96 enable the D-channel:
ENL DCH X
4. In LD 96 check the current status of the D-channel (the system should respond with
DCH x EST meaning that the D-channel is established and operational).
STAT DCH X
ISDN Primary Rate Interface Maintenance November 2011 91
