Azbil dcp551 mark II User Manual

7-12
■ Event configuration data settings
The event type setting of each event determines whether
auxiliary setting 1 or auxiliary setting 2 is on or off, their
meaning, unit and range. For details, see ■ Settings by event
type on the following pages.
0 E01-t 1
Event 1 event type
0 E02-t 4 Event 2 event type
---- E01-2 3 Event 1 auxiliary setting 2
---- E01-1 2 Event 1 auxiliary setting 1
---- E02-1 5 Event 2 auxiliary setting 1
---- E02-2 6 Event 2 auxiliary setting 2
0 E03-t 7 Event 3 event type
---- E03-1 8 Event 3 auxiliary setting 1
---- E03-2 9 Event 3 auxiliary setting 2
0 E04-t 10 Event 4 event type
---- E04-1 11 Event 4 auxiliary setting 1
---- E04-2 12 Event 4 auxiliary setting 2
0 E05-t 13 Event 5 event type
---- E05-1 14 Event 5 auxiliary setting 1
---- E05-2 15 Event 5 auxiliary setting 2
0 E06-t 16 Event 6 event type
---- E06-2 17 Event 6 auxiliary setting 1
---- E06-3 18 Event 6 auxiliary setting 2
0 E07-t 19 Event 7 event type
---- E07-1 20 Event 7 auxiliary setting 1
---- E07-2 21 Event 7 auxiliary setting 2
0
0
E08-t 22 Event 8 event type
---- E08-1 23 Event 8 auxiliary setting 1
---- E08-2 24 Event 8 auxiliary setting 2
---- E09-1 26 Event 9 auxiliary setting 1
E09-t 25 Event 9 event type
---- E09-2 27 Event 9 auxiliary setting 2
0 E10-t 28 Event 10 event type
---- E10-1 29 Event 10 auxiliary setting 1
---- E10-2 30 Event 10 auxiliary setting 2
0 E11-t 31 Event 11 event type
---- E11-1 32 Event 11 auxiliary setting 1
---- E11-2 33 Event 11 auxiliary setting 2
0 E12-t 34 Event 12 event type
---- E12-1 35 Event 12 auxiliary setting 1
---- E12-2 36 Event 12 auxiliary setting 2
0 E13-t 37 Event 13 event type
---- E13-1 38 Event 13 auxiliary setting 1
---- E13-2 39 Event 13 auxiliary setting 2
0 E14-t 40 Event 14 event type
---- E14-1 41 Event 14 auxiliary setting 1
---- E14-2 42 Event 14 auxiliary setting 2
0 E15-t 43 Event 15 event type
---- E15-1 44 Event 15 auxiliary setting 1
---- E15-2 45 Event 15 auxiliary setting 2
0 E16-t 46 Event 16 event type
---- E16-1 47 Event 16 auxiliary setting 1
---- E16-2 48 Event 16 auxiliary setting 2
Item code
Item
No.
User
settings
Settings and descriptions
Factory default
settings
Chapter 7. PARAMETER SETUP
