9 - 3 Load Procedures
9-6
Insert a memory card when the DCP551 is in the READY mode and the normal display mode, and variable
parameter PA05 has been set to 0. Press the LOAD key to start a load operation. “CArd ” is displayed in display
panel 1 and “LOAd ” is displayed in display panel 2. An error code appears if something should go wrong during
the save operation.
Load menu
When the LOAD key is pressed in the normal display mode, the load menu panel
is displayed. Use the ENTER key to select the desired menu.
Press the ENTER key to display the desired menu in the message display panel.
The DISP key returns you to the normal display mode.
Note, however, that an autoload operation is performed when the LOAD key is
pressed and variable parameter PA05 is set to 1.
For details, see “Section 9-4 Autoload” (page 9-10).
A RAM memory card whose internal batteries are too low, cause a card battery
alarm panel to be displayed before the Load menu panel is displayed.
Normal display mode
Load individual programs
LOAD key
ENTER key
Load Card--->DCP
Program?
Procedures for loading single programs (page 9-7)
Load all programs
Load Card--->DCP
All Programs?
ENTER key
Procedures for loading all programs (page 9-8)
Load setup data
Load Card--->DCP
SETUP Data?
ENTER key
Procedures for loading setup data (page 9-8)
Load variable parameters
Load Card--->DCP
PARA Data?
ENTER key
Procedures for loading variable parameters (page 9-8)
Load PID parameters
Load Card--->DCP
PID Data?
ENTER key
Procedures for loading PID parameters (page 9-8)
(including fixed command control data)
Load event configuration data
Load Card--->DCP
EVENT Data?
ENTER key
Procedures for loading event configuration data (page 9-9)
Load all parameters
Load Card--->DCP
All Parameters?
ENTER key
Procedures for loading all parameters (page 9-9)
DISP key
key
key
key
key
key
key
key
key
key
key
key
key
key
key
