9 - 4 Autoload
9-10
Insert a memory card, press the LOAD key or use external switch inputs in the READY mode and the normal
display mode to load file number 1 on the memory card as program 1 onto the DCP551.
■ Key operated autoload procedure
● Conditions
Memory card : Program has been saved to file number 1
Variable parameter : PA05 set to 1
Mode : READY mode, normal display mode
● Operation and action
Insert a memory card and press the .
The DCP551 operates as follows.
“AUtO ” is displayed in display panel 1 and “LOAd ” is displayed in display panel
1.
• When program number 1 has been loaded onto the DCP551, program number
1 disappears.
• File number 1 on a memory card is loaded onto the DCP551 as program
number 1.
• When a load operation is successful, the “AUtO ” and “LOAd ” indications go
off and the normal display mode appears.
Unless the number of a program is selected using external switch inputs,
program 1 in segment 1 is selected.
• If the load operation fails, the “AUtO ” and “LOAd ” indications stay on and an
error code is displayed in the message panel.
When an error has occurred, press the DISP key to return to the normal display
mode.
Handling Precautions
A normal load operation is not possible when variable parameter PA05 is
set to 1. A normal load operation requires that this parameter is set to 0.
Chapter 9. MEMORY CARD OPERATIONS
