2-6
■ Key chord functions
PROG + RUN/HOLD : Reset key
Press the RUN/HOLD key while holding down the PROG key in basic status
display to perform a RESET.
The READY mode is invoked when a reset is performed in the RUN, HOLD,
FAST, END, or READY FAST modes. This RESET operation does not work
in the READY mode.
PROG + DISP : Advance key
Press the DISP key while holding down the PROG key in the program run mode
in basic status display to perform an ADV (advance) operation. The next segment
is displayed when this action is performed in the RUN, HOLD, FAST, END, or
READY FAST modes. This ADV operation does not work in the READY mode.
FUNC + : Fast key
Press the key while holding down the FUNC key in the program run mode
in basic status display to perform a FAST operation.
The system changes from the RUN or HOLD mode to the FAST mode. If the
system is in the READY mode, it goes to the READY FAST mode.
Chapter 2. NAMES AND FUNCTIONS OF PARTS
Classification
Program setting
Program copy
General reset
Memory card
operation
(available on the
DCP551A*****
model only)
Erases or resets a set value.
(When a set value flickers.)
Key operation
FUNC + CLR
Cancels change in set value.
(When a set value flickers.)
DISP
FUNC + ENTERInserts or delete a segment when a pattern SP setting is started.
FUNC + PROG
Changes RAMP-X RAMP-T or RAMP-X RAMP-E when a
pattern SP setting is completed.
Starts a program number change.
DISPEnds program setting.
+ PROG
Starts program copy. (In basic display status)
Changes program number at copy destination.
ENTERExecutes the copy.
(When a set value flickers.)
DISPEnds program copy.
SAVEStarts a data write operation to the memory card.
(In basic display status)
Writes data to the memory card.
LOADStarts a data read operation from the memory card.
(In basic display status)
Reads data from the memory card.
Changes selected memory card operation.
ENTER
Enters memory card operation.
DISP
Interrupts memory card operation.
FUNC + CLR + MESSAGE
Returns a check status of the general reset. (In basic display status)
ENTER
Executes a general reset.
DISP
Interrupts a general reset.
Function
